| Network |
Remote Connection: 128
Total Bandwidth: 128 Mbps
Network Protocol: TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, ISCSI, UPnP™, HTTPS, ONVIF
Network Interface
1, RJ45 10M/100M/1000M
Self-Adaptive Ethernet Interface |
| Video And Audio |
IP Video Input
2-Ch (Up To 18-Ch)
Enhanced IP Mode On:
8-Ch (Up To 24-Ch), Each Up To 4 Mbps
Up To 6 MP Resolution
Support H.265+/H.265/H.264+/H.264 IP Cameras
Analog Video Input
16-Ch
BNC Interface (1.0 Vp-P, 75 Ω), Supporting Coaxitron Connection
Incoming Bandwidth
96 Mbps
HDTVI Input
3K@20 Fps, 4 MP@30 Fps, 4 MP@25 Fps, 1080p@30 Fps, 1080p@25 Fps, 720p@60 Fps, 720p@50 Fps, 720p@30 Fps, 720p@25 Fps
AHD Input
4 MP@25 Fps, 4 MP@30 Fps, 1080p@25 Fps, 1080p@30 Fps, 720p@25 Fps, 720p@30 Fps HDCVI Input
4 MP@25 Fps, 4 MP@30 Fps, 1080p@25 Fps, 1080p@30 Fps, 720p@25 Fps, 720p@30 Fps CVBS Input
PAL/NTSC
HDMI Output
1-Ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
VGA Output
1-Ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
Audio Input
1-Ch, RCA (2.0 Vp-P, 1 KΩ)
16-Ch Via Coaxial Cable
Audio Output
1-Ch, RCA (Linear, 1 KΩ)
Two-Way Audio
1-Ch, RCA (2.0 Vp-P, 1 KΩ) (Using The First Audio Input)
Synchronous Playback
16-Ch |
